Product Description
 |  |  | |
| Name | NU 208 ECKP | NU 208 ECKP C3 | NU 208 ECKP/C3 |
| Brand | SKF | SKF | SKF |
| Size (mm) | 80x40x18(mm) | ||
| Bore Diameter (mm) | 80(mm) | ||
| Outer Diameter (mm) | 40(mm) | ||
| Width (mm) | 18(mm) | ||
| d | 40 mm 1.5748 in | ||
| D | 80 mm 3.1496 in | ||
| B | 18 mm 0.7087 in | ||
| D1 | 67.4 mm 2.6535 in | ||
| F | 49.5 mm 1.9488 in | ||
| r1,2 - min. | 1.1 mm 0.0433 in | ||
| r3,4 - min. | 0.6 mm 0.0236 in | ||
| s | 1.4 mm 0.0551 in | ||
| da - min. | 47 mm 1.8504 in | ||
| da - max. | 48 mm 1.8898 in | ||
| Da - max. | 72.8 mm 2.8661 in | ||
| ra - max. | 1 mm 0.0394 in | ||
| Basic dynamic load rating - C | 62 kN | ||
| Basic static load rating - C0 | 53 kN | ||
| Fatigue load limit - Pu | 6.7 kN | ||
| Reference speed | 9500 r/min | ||
| Limiting speed | 11000 r/min | ||
| Calculation factor - kr | 0.15 |
